Fixed and Sliding Ceilings

Seesky LUZ ceilings are strong and durable aluminum systems. These enclosures protect us from adverse weather conditions while creating new spaces.

Thanks to its motorized trailing panel system, Seesky LUZ allows gradual ventilation of the covered space, so that the opening of the panels can be adjusted as desired. It is a non-seasonal system, ensuring its use all year round, and its efficiency and versatility make it the perfect product for any outdoor space.

With our Seesky LUZ ceilings you will be able to expand spaces and enjoy your terrace, yard, garden, penthouse, restaurant, recreation area, throughout the year without carrying out works of any kind and with top quality finishes and durability.

See Catalogue
seesky luz ceiling form


Seesky LUZ ceilings, the most durable and resistant option on the market

Configurations

FIXED


  Laminated Chamber Polycarbonate
(solar control)
  4+4 3+3/6/4 16
Max. Width Panel 1100 mm. 1100 mm. 1100 mm.
Max. Length Panel 4000 mm. 3000 mm. 6000 mm.
Max. Output 6000 mm. 6000 mm. 6000 mm.

SLIDING


  Laminated Chamber Polycarbonate
(solar control)
  4+4 3+3/6/4 16
Max. Width Panel 1200 mm. 1200 mm. 1200 mm.
Max. Length Panel 1300 mm. 1300 mm. 2500 mm.
Max. Output 6000 mm. 6000 mm. 6000 mm.

DISTANCE BETWEEN PILLARS


  Without enclosure ONE - MAX - ECO With loadof snow
Standard 4500 mm. 3000 mm. 3000 mm.
Reinforced 6000 mm. 4500 mm. 4500 mm.

PANELS PER LANE


Panels
By simple blind guide
2 3 4 5
Opening 50% 66% 75% 80%

Accessories and Components



water evacuation fixed and sliding ceiling

80mm water evacuation drainage system.

The 80mm diameter of the drainage system easily transport the water towards the pillars.

led light fixed and sliding ceiling

Possibility of LED light in beams

The incorporation of LED light in the beams allows the use of the system 24 hours a day.

installation fixed and sliding ceiling

Installation from inside

The panels are mounted from the ceiling, inside the system itself.

bearing-free sliding ceiling

Bearing-free sliding system

The sliding of the panels is carried out without bearings, avoiding continuous maintenance.

Finishes



acabados C3 Systems


MOST USED COLORS



Lacquered



White



9006 nature



7016 mate



7016 tx



9011 mate



1013



8014



8017



Anodized



Silver Anodized



Stainless Anodized



Extruded Wood Finishes



BTO – 100



BTO – 12



FTO – 160



ALUCOLOR REF 606




Advantages



· 100% use of natural light.

· They combine and integrate perfectly with glass enclosures.

· Does not distort the environment.

· Resistant to adverse weather conditions.

· Ideal system for the HORECA sector, attics and porches.

· Perfect for use and enjoyment 365 days a year.

· Ventilation ensured thanks to the movement of the panels.

· Create new spaces, previously wasted.

· Materials and finishes of high quality and durability.

· Its multiple options make it a versatile system.





Tests and Certificates

Seesky-luz has the certificates established by legal regulations, issued by the corresponding certification bodies.


wind load resistance fixed and sliding ceiling

Wind load resistance
CLASE 6 - UNE-EN 1932:2014
486,67 N/ m² = 102,3 km/h

water tightness fixed and sliding ceiling

Water tightness
UNE-EN 14963:2007
3,5 l/ (m²xmin)

resistance to snow load fixed and sliding ceiling

Resistance to snow load
UNE-EN 12833:2011
250,22 kg/ m²


two years warranty fixed and sliding ceiling

2 YEARS WARRANTY

*  See warranty conditions.

(To see the guarantee in detail, download the general conditions of sale in the client area of the web)
made in spain fixed and sliding ceiling

MADE IN SPAIN

The systems are manufactured in Spain. All components are designed by our team of engineers and manufactured under the strictest quality controls


international regulations fixed and sliding ceiling

INTERNATIONAL REGULATIONS

Sessky complies with the international standards of Qualanod, Qualideco and Qualicoat in all its lacquer surface treatment processes.


ce marking fixed and sliding ceiling

CE MARKING

Seesky is CE marked. We identify our products, incorporate tests, and endorse the certification process




CATALOGUE

If you need a more detailed and technical information about our bioclimatic pergola, download our catalogue here.

DOWNLOAD CATALOGUE
