Clamping Systems
Introducing our innovative e-Orbita clamp photovoltaic glass clamps, ddesigned to offer a safe, efficient and elegant solution
It is a patented system with an innovative design made of high quality materials. Our clamps clamps guarantee a firm and secure hold of the photovoltaic glass, providing peace of mind and confidence to our customers.
Single clamp kit
Double clamp kit
T-profile
U-profile
A patented system with an innovative design that guarantees a firm and secure grip.
Single Clamp Kit
| Code | Glass Thickness | Dimensions | Finish |
|---|---|---|---|
| 6940 | 8mm | 130 mm |  RAW
|
 RAL 5004 Matt
|
Double Clamp Kit
| Code | Glass Thickness | Dimensions | Finish |
|---|---|---|---|
| 6941 | 8mm | 130 mm | Raw
|
| RAL 5004 Matt
|
Clamp Profile Set
A - Single Clamp Profile Set on Bars
| Code | Dimensions | Finish | Units per Package |
|---|---|---|---|
| 6942 | 6300 mm | RAW
|
4 barras |
| RAL 5004 Matt
|
4 barras |
Clamp Profile Set
B - Double Clamp Profile Set on Bars
| Code | Dimensions | Finish | Units per Package |
|---|---|---|---|
| 6943 | 6300 mm | RAW
|
4 bars |
| RAL 5004 Matt
|
4 bars |
For frameless photovoltaic modules
Available in both individual kits and 6,300mm long sets
Material: Aluminum
Suitable for side and central mounting
The material is supplied unmachined
Certification and Quality
Aluminium alloys
Standard UNE EN 12020-1 - Extruded aluminium alloy 6063 and T6 heat treatment - Complies with Standard UNE-EN 573-3 - Standard UNE-EN 755-2.
STRAIGHT LIP BUBBLE - EPDM
EPDM rubber is resistant to abrasion and wear.
CERTIFIED BY
Qualanod, Qualideco, Qualicoat
Item List
For more information about the e-Orbita range of items, you can download our item list here.
